Victron Inverter RS Smart 48V/6000VA 230V

Description

Victron Inverter RS Smart 48V/6000VA 230V – pure sine wave inverter for 48 V batteries (without solar input)

This item (PIN482600000) is the Victron Inverter RS Smart 48/6000 230V – a powerful pure sine wave inverter that converts power from a 48 V battery into 230 V AC. It has no built-in solar charge controller: solar panels are connected via a separate MPPT controller on the DC side or via a solar inverter on the AC output (AC coupling). Battery and inverter data can be viewed on the built-in display and via Bluetooth in the VictronConnect app.

Benefits

  • Powerful pure sine wave: 6000 VA, 4500 W continuous at 40 °C and 9 kW peak power for 3 seconds to start heavy loads.
  • Light and efficient: High-frequency design weighing 11 kg, with up to 96.5 % efficiency and a no-load consumption of 20 W.
  • AC coupling of solar panels: An external solar inverter on the AC output can charge the battery with up to 5000 W (max. 88 A charging current).
  • Bluetooth and GX connection: Monitor and configure the inverter in VictronConnect, and connect a GX device via VE.Can for remote monitoring in VRM.
  • Expandable: Up to 12 units can be connected in parallel, and 3-phase systems can be built with up to 4 units per phase.

Applications

  • Off-grid systems with a 48 V battery bank, where the solar panels charge the battery via separate MPPT controllers.
  • Systems where a solar inverter is AC-coupled to the inverter's output.
  • Summer houses, workshops and larger mobile systems that need 230 V from a 48 V battery.

Specifications

Specification Details
Nominal battery voltage 48 V
DC input range 38–62 V
Rated power 6000 VA
Continuous power at 40 °C 4500 W
Continuous power at 65 °C 3000 W
Peak power 9 kW for 3 sec. / 7 kW for 4 min.
Output voltage 230 V AC ±2 %, 50 Hz (can be set to 60 Hz)
Max. continuous AC current 25 A
Max. efficiency 96.5 % (at 1 kW load)
No-load consumption 20 W
Solar input (MPPT) No – solar panels are connected via a separate MPPT or AC coupling
Max. AC-coupled solar power 5000 W (external solar inverter on the AC output)
Max. charging current 88 A at 57.6 V
Charging voltage Programmable 36–60 V (absorption 57.6 V / float 55.2 V by default)
Communication Bluetooth, VE.Can (GX device) and VE.Direct
Inputs and outputs Programmable relay, 2 analogue/digital inputs, remote on/off
Parallel and 3-phase operation Up to 12 units in parallel / 4 units per phase
Enclosure rating IP21
Operating temperature range -40 to +65 °C (fan-cooled)
Battery connection M8 bolts
Dimensions (h × w × d) 425 × 440 × 125 mm
Weight 11 kg
Item number PIN482600000

Download datasheet (PDF)

Victron Inverter RS Smart 48V/6000VA 230V

Product form

9.989,00 kr Incl. VAT

Køb nu – betal senere. Vælg Klarna ved kassen.

  • Spænding48V
Free pickup in our shop(s)

2-4 day delivery

    Hurtig levering2-4 hverdage på lagervarer
    14 dages returretGælder privatkunder
    Op til 5 års garantiProducentgaranti fra Victron + 24 mdr. reklamationsret
    Dansk teknisk support+45 60 46 84 10

    Sikker betaling med

    • MobilePay
    • Visa
    • Mastercard
    • Maestro
    • American Express
    • Apple Pay
    • Google Pay
    • Klarna
    • PayPal
    • Shop Pay

    Victron Inverter RS Smart 48V/6000VA 230V – pure sine wave inverter for 48 V batteries (without solar input)This item (PIN482600000)... Read more

    Warranty and lifespan

    Victron-produkter har op til 5 års producentgaranti fra Victron Energy – ud over din 2 års reklamationsret. Garantien følger Victrons garantivilkår. Har du spørgsmål til garantien, så ring til os på +45 60 46 84 10.

    Delivery and returns

    Delivery in 2-4 business days throughout Denmark. Special batteries and items not in stock may have a delivery time of up to 1 week. 14-day right of return. Read more in our delivery terms and return policy.

    Pay however you like

    Pay with MobilePay, card, Apple Pay, Google Pay or PayPal – or choose Klarna and pay later. All payments are encrypted and handled securely. Read about delivery

    Description

    Victron Inverter RS Smart 48V/6000VA 230V – pure sine wave inverter for 48 V batteries (without solar input)

    This item (PIN482600000) is the Victron Inverter RS Smart 48/6000 230V – a powerful pure sine wave inverter that converts power from a 48 V battery into 230 V AC. It has no built-in solar charge controller: solar panels are connected via a separate MPPT controller on the DC side or via a solar inverter on the AC output (AC coupling). Battery and inverter data can be viewed on the built-in display and via Bluetooth in the VictronConnect app.

    Benefits

    • Powerful pure sine wave: 6000 VA, 4500 W continuous at 40 °C and 9 kW peak power for 3 seconds to start heavy loads.
    • Light and efficient: High-frequency design weighing 11 kg, with up to 96.5 % efficiency and a no-load consumption of 20 W.
    • AC coupling of solar panels: An external solar inverter on the AC output can charge the battery with up to 5000 W (max. 88 A charging current).
    • Bluetooth and GX connection: Monitor and configure the inverter in VictronConnect, and connect a GX device via VE.Can for remote monitoring in VRM.
    • Expandable: Up to 12 units can be connected in parallel, and 3-phase systems can be built with up to 4 units per phase.

    Applications

    • Off-grid systems with a 48 V battery bank, where the solar panels charge the battery via separate MPPT controllers.
    • Systems where a solar inverter is AC-coupled to the inverter's output.
    • Summer houses, workshops and larger mobile systems that need 230 V from a 48 V battery.

    Specifications

    Specification Details
    Nominal battery voltage 48 V
    DC input range 38–62 V
    Rated power 6000 VA
    Continuous power at 40 °C 4500 W
    Continuous power at 65 °C 3000 W
    Peak power 9 kW for 3 sec. / 7 kW for 4 min.
    Output voltage 230 V AC ±2 %, 50 Hz (can be set to 60 Hz)
    Max. continuous AC current 25 A
    Max. efficiency 96.5 % (at 1 kW load)
    No-load consumption 20 W
    Solar input (MPPT) No – solar panels are connected via a separate MPPT or AC coupling
    Max. AC-coupled solar power 5000 W (external solar inverter on the AC output)
    Max. charging current 88 A at 57.6 V
    Charging voltage Programmable 36–60 V (absorption 57.6 V / float 55.2 V by default)
    Communication Bluetooth, VE.Can (GX device) and VE.Direct
    Inputs and outputs Programmable relay, 2 analogue/digital inputs, remote on/off
    Parallel and 3-phase operation Up to 12 units in parallel / 4 units per phase
    Enclosure rating IP21
    Operating temperature range -40 to +65 °C (fan-cooled)
    Battery connection M8 bolts
    Dimensions (h × w × d) 425 × 440 × 125 mm
    Weight 11 kg
    Item number PIN482600000

    Download datasheet (PDF)
