Victron SmartSolar MPPT 450/100 - MC4

Description

Victron SmartSolar MPPT 450/100 - MC4 – MPPT solar charge controller for efficient solar charging

The Victron SmartSolar MPPT 450/100 - MC4 is an MPPT solar charge controller from Victron Energy for battery banks. It delivers up to 100 A of charging current, and built-in Bluetooth allows you to monitor operation and change settings directly from the VictronConnect app.

Benefits

  • Up to 100 A charging current: Charges the battery bank quickly and gently.
  • Built-in Bluetooth: Setup, monitoring, and firmware updates are performed wirelessly in the VictronConnect app — no extra display required.
  • Encapsulated electronics (IP21): Can be installed in technical rooms, boats, motorhomes, and site huts.

Application

  • Motorhome, caravan, and van with a solar panel on the roof.
  • Boat, where the service battery needs to be kept fully charged throughout the season.
  • Summer house, allotment garden, and site hut without a fixed grid connection.

Specifications

Specification Details
Programmable charge voltage range Minimum: 36V / Maximum: 60 V (8)
Absorption charge voltage Default : 57.6 V (adjustable)
Float charge voltage Default : 55.2 V (adjustable)
Max. charge current 100 A
Battery temperature sensor included
Battery voltage sensing Yes
Max. DC PV voltage 450 V
Start-up voltage 120 V
MPPT operating voltage range 65 – 450 V (1)
Number of MPP Trackers 2
Max. operational PV input current 16 A per tracker
Max. PV short circuit current reverse polarity protection 20 A per tracker
Max. DC output charging power 4000 W per tracker / 5760 W total
Max. PV array size per tracker 7200 Wp (450 V × 20 A)
PV Isolation fail level 100 kΩ
Synchronised Parallel Operation Yes, up to 25 units with VE.Can
Programmable relay Yes
Protection c, d, e
Data Communications VE.Direct port, VE.Can port & SmartSolar Bluetooth (7)
Bluetooth frequency 2402 – 2480 MHz
Bluetooth power 4dBm
General purpose analog/digital in port Yes, 2x
Remote on/off Yes
Operating temperature range -40 to +60 °C (fan cooled)
Humidity (non-condensing) max. 95 %
Environmental conditions indoor type 1, conditioned
Suitable for wet locations No
Pollution degree PD2
Max. altitude 2000 m
Overvoltage category OVCII
Material steel, blue RAL 5012
Protection class IP21
Battery connection Two M8 bolts, 1x Positive and 1x Negative
Power terminals PV input MC4 Connectors
Weight 7.9 kg
Dimensions (h × w × d) 442 × 310 × 127 mm
Safety EN-IEC 62109-1
Country of Origin Designed in Netherlands, Made in India
Nominal voltage 12/24/48 V
Item number SCC145110512

Download datasheet (PDF)
